High Quality and Good Price Aluminum Plate Sheet Expanded Metal Mesh

Thickness(mm)	SWD(mm)	LWG(mm)	wire stems width(mm)	wire stems width(mm)	wire stems width(mm)	Weight(kg/m2)
0.5	2.5	4.5	0.5	0.5	1	1.8
0.5	10	25	0.5	0.6	2	0.73
0.6	10	25	1	0.6	2	1
0.8	10	25	1	0.6	2	1.25
1	10	25	1.1	0.6	2	1.77
1	15	40	1.5	2	4	1.85
1.2	10	25	1.1	2	4	2.21
1.2	15	40	1.5	2	4	2.3
1.5	15	40	1.5	1.8	4	2.77
1.5	23	60	2.6	2	3.6	2.77
2	18	50	2.1	2	4	3.69
2	22	60	2.6	2	4	3.69
3	40	80	3.8	2.	4	5.00
4	50	100	4	2	2	11.15
4	60	120	4	2	7.5	4.0
4	60	120	4	2	10	3.0
4	100	120	4	2	12	2.5
4.5	50	100	5	2	2.7	11.15
5	50	100	5	1.4	2.6	12.39
5	75	100	5	2	10	3.0
6	50	100	6	2	2.5	17.35
8	50	100	8	2	2.1	28.26

EXPANDED METAL MESH High Quality and Good Price Aluminum Plate Sheet Expanded Metal Mesh

Expanded metal mesh is the industry a variety of metal mesh, also known as expanded metal, diamond wire mesh, iron wire mesh, metal expansion net, heavy steel plate net, pedal mesh, stainless steel mesh, granary, antenna wire mesh, filter mesh, acoustics meshes, etc

Expanded metal mesh: low carbon steel, stainless steel plate, aluminum plate, copper plate, nickel plate, aluminum and magnesium alloy plate and other metal plate

Expanded metal mesh surface treatment: PVC dip molding(plastic spraying, plastic coated), hot-dipped galvanized, electric galvanized, spray paint, etc

Expanded metal mesh specification

High Quality and Good Price Aluminum Plate Sheet Expanded Metal Mesh

1. Is your samples free?
Yes, we can provide free samples to my clients.

2. How many days will the samples be finished?
Generally the samples will be sent immediately by the air express in 2~3 days if the goods are in stock.

3. And how about the mass production?
Normally within 20-25 days according to your order.

4. Are you a manufacture?
Yes, we have been in providing the products in this field for 15 years.

5. Is customized availables?
Yes, we can OEM according to your detailed drawings.

High Quality and Good Price Aluminum Plate Sheet Expanded Metal Mesh
